Getting Started with Multi-Node Kubernetes Cluster using LinuxKit

Estimated Reading Time: 5 minutes

Here’s a BIG news for the entire Container Community – “Kubernetes Support is coming to Docker Platform“. What does this mean? This means that developers and operators can now build apps with Docker and seamlessly test and deploy them using both Docker Swarm and Kubernetes. This announcement was made on the first day of Dockercon EU 2017 Copenhagen where Solomon Hykes, Founder of Docker invited Kubernetes Co-Founder  Tim Hockin on the stage for the first time. Tim welcomed the Docker family to the vibrant Kubernetes world.

In case you missed out the news, here are the important takeaways from Docker-Kubernetes announcement –

  • Kubernetes support will be added to Docker Enterprise Edition for the first time.
  • Kubernetes support will be added optionally to Docker Community Edition for Mac and Windows.
  • Kubernetes and Docker Swarm both orchestrators will be available under Docker Platform.
  • Kubernetes integration will be made available under Moby projects too.

Docker Inc firmly believes that bringing Kubernetes to Docker will simplify and advance the management of Kubernetes for developers, enterprise IT and hackers to deliver the advanced capabilities of Docker to a broader set of applications.





In case you want to be first to test drive, click here to sign up and be notified when the beta is ready.

Please be aware that the beta program is expected to be ready at the end of 2017.

Can’t wait for beta program? Here’s a quick guide on how to get Multi-Node Kubernetes cluster up and running using LinuxKit.

Under this blog post, we will see how to build 5-Node Kubernetes Cluster using LinuxKit. Here’s the bonus – We will try to deploy WordPress application on top of Kubernetes Cluster. I will be building it on my macOS Sierra 10.12.6 system running the latest Docker for Mac 17.09.0 Community Edition up and running.

Pre-requisite:

  1. Ensure that the latest Docker release is up and running.

       2. Clone the LinuxKit repository:

sudo git clone https://github.com/ajeetraina/linuxkit
cd projects/kubernetes/

3. Execute the below script to build Kubernetes OS images using LinuxKit & Moby:

sudo chmod +x script4k8s.sh

All I have done is put all the manual steps under a script as shown below:





This should build up Kubernetes OS image.

Run the below command to know the IP address of the kubelet container:

ip adds show dev eth0



You can check the list of tasks running as shown below:

Once this kubelet is ready, it’s time to login into it directly from a new terminal:

sudo ./ssh_into_kubelet.sh 192.168.65.3

So you have already SSH into the kubelet container rightly named “LinuxKit Kubernetes Project”.

We are going to mark it as “Master Node”.

Initializing the Kubernetes Master Node

Now it’s time to manually initialize master node with Kubeadm command as shown below:

sudo kubeadm-init.sh

Wait for few minutes till kubeadm command completes. Once done, you can use kubeadm join argument as shown below:



Your Kubernetes master node gets initialized successfully as shown below:





It’s time to run the below list of commands command to join the list of worker nodes:

pwd
/Users/ajeetraina/linuxkit/projects/kubernetes
sudo ./boot.sh 1 --token 4cec03.1a7ccb44115f427a 192.168.65.3:6443
sudo ./boot.sh 2 --token 4cec03.1a7ccb44115f427a 192.168.65.3:6443
sudo ./boot.sh 3 --token 4cec03.1a7ccb44115f427a 192.168.65.3:6443
sudo ./boot.sh 4 --token 4cec03.1a7ccb44115f427a 192.168.65.3:6443



It brings up 5-Node Kubernetes cluster as shown below:



Deploying WordPress Application on Kubernetes Cluster:

Let us try to deploy a WordPress application on top of this Kubernetes Cluster.

Head over to the below directory:

cd linuxkit/projects/kubernetes/wordpress



Creating a Persistent Volume

kubectl create -f local-volumes.yaml

The content of local-volumes.yml look like:


This creates 2 persistent volumes:

Verifying the volumes:



Creating a Secret for MySQL Password

kubectl create secret generic mysql-pass --from-literal=password=mysql123


Verifying the secrets using the below command:
kubectl get secrets



Deploying MySQL:

kubectl create -f mysql-deployment.yaml



Verify that the Pod is running by running the following command:

kubectl get pods



Deploying WordPress:

kubectl create -f wordpress-deployment.yaml

By now, you should be able to access WordPress UI using the web browser.

Did you find this blog helpful?  Feel free to share your experience. Get in touch @ajeetsraina

If you are looking out for contribution/discussion, join me at Docker Community Slack Channel.



Docker, Prometheus & Pushgateway for NVIDIA GPU Metrics & Monitoring

Estimated Reading Time: 6 minutes

In my last blog post, I talked about how to get started with NVIDIA docker & interaction with NVIDIA GPU system. I demonstrated NVIDIA Deep Learning GPU Training System, a.k.a DIGITS by running it inside Docker container. ICYMI –  DIGITS is essentially a webapp for training deep learning models and is used to rapidly train the highly accurate deep neural network (DNNs) for image classification, segmentation and object detection tasks.The currently supported frameworks are: Caffe, Torch, and Tensorflow. It simplifies common deep learning tasks such as managing data, designing and training neural networks on multi-GPU systems, monitoring performance in real time with advanced visualizations, and selecting the best performing model from the results browser for deployment.



In a typical HPC environment where you run 100 and 100s of NVIDIA GPU equipped cluster of nodes, it becomes important to monitor those systems to gain insight of the performance metrics, memory usage, temperature and utilization. . Tools like Ganglia & Nagios etc. are very popular due to their scalable  & distributed monitoring architecture for high-performance computing systems such as clusters and Grids. It leverages widely used technologies such as XML for data representation, XDR for compact, portable data transport, and RRDtool for data storage and visualization. But with the advent of container technology, there is a need of modern monitoring tools and solutions which works well with Docker & Microservices.

It’s all modern world of Prometheus Stack…

Prometheus is 100% open-source service monitoring system and time series database written in Go.It is a full monitoring and trending system that includes built-in and active scraping, storing, querying, graphing, and alerting based on time series data. It has knowledge about what the world should look like (which endpoints should exist, what time series patterns mean trouble, etc.), and actively tries to find faults.

How is it different from Nagios?

Though both serves a purpose of monitoring, Prometheus wins this debate with the below major points –

  • Nagios is host-based. Each host can have one or more services, which has one check.There is no notion of labels or a query language. But Prometheus comes with its robust query language called “PromQL”. Prometheus provides a functional expression language that lets the user select and aggregate time series data in real time. The result of an expression can either be shown as a graph, viewed as tabular data in Prometheus’s expression browser, or consumed by external systems via the HTTP API.
  • Nagios is suitable for basic monitoring of small and/or static systems where blackbox probing is sufficient. But if you want to do whitebox monitoring, or have a dynamic or cloud based environment then Prometheus is a good choice.
  • Nagios is primarily just about alerting based on the exit codes of scripts. These are called “checks”. There is silencing of individual alerts, however no grouping, routing or deduplication.

Let’s talk about Prometheus Pushgateway..

Occasionally you will need to monitor components which cannot be scraped. They might live behind a firewall, or they might be too short-lived to expose data reliably via the pull model. The Prometheus Pushgateway allows you to push time series from these components to an intermediary job which Prometheus can scrape. Combined with Prometheus’s simple text-based exposition format, this makes it easy to instrument even shell scripts without a client library.

The Prometheus Pushgateway allow ephemeral and batch jobs to expose their metrics to Prometheus. Since these kinds of jobs may not exist long enough to be scraped, they can instead push their metrics to a Pushgateway. The Pushgateway then exposes these metrics to Prometheus. It is important to understand that the Pushgateway is explicitly not an aggregator or distributed counter but rather a metrics cache. It does not have statsd-like semantics. The metrics pushed are exactly the same as you would present for scraping in a permanently running program.For machine-level metrics, the textfile collector of the Node exporter is usually more appropriate. The Pushgateway is intended for service-level metrics. It is not an event store

Under this blog post, I will showcase how NVIDIA Docker, Prometheus & Pushgateway come together to  push NVIDIA GPU metrics to Prometheus Stack.

Infrastructure Setup:

  • Docker Version: 17.06
  • OS: Ubuntu 16.04 LTS
  • Environment : Managed Server Instance with GPU
  • GPU: GeForce GTX 1080 Graphics card

Cloning the GITHUB Repository

Run the below command to clone the below repository to your Ubuntu 16.04 system equipped with GPU card:

git clone https://github.com/ajeetraina/nvidia-prometheus-stats

Script to bring up Prometheus Stack(Includes Grafana)

Change to nvidia-prometheus-stats directory with proper execute permission & then execute the ‘start_containers.sh’ script as shown below:

cd nvidia-prometheus-stats
sudo chmod +x start_containers.sh
sudo sh start_containers.sh

This script will bring up 3 containers in sequence – Pushgateway, Prometheus & Grafana

Executing GPU Metrics Script:

NVIDIA provides a python module for monitoring NVIDIA GPUs using the newly released Python bindings for NVML (NVIDIA Management Library). These bindings are under BSD license and allow simplified access to GPU metrics like temperature, memory usage, and utilization.

Next, under the same directory, you will find a python script called “test.py”.

Execute the script (after IP under line number – 124 as per your host machine) as shown below:

sudo python test.py

That’s it. It is time to open up Prometheus & Grafana UI under http://<IP-address>:9090

Just type gpu under the Expression section and you will see the list of GPU metrics automatically turned up as shown below:

Accessing the targets

Go to Status > Targets to see what targets are accessible. The Status should show up UP.

Click on Push gateway Endpoint to access the GPU metrics in details as shown:

Accessing Grafana

 You can access Grafana through the below link:

                                          http://<IP-address>:3000



Did you find this blog helpful?  Feel free to share your experience. Get in touch @ajeetsraina

If you are looking out for contribution/discussion, join me at Docker Community Slack Channel.
