Getting Started with Multi-Node Kubernetes Cluster using LinuxKit

Here’s a BIG news for the entire Container Community – “Kubernetes Support is coming to Docker Platform“. What does this mean? This means that developers and operators can now build apps with Docker and seamlessly test and deploy them using both Docker Swarm and Kubernetes. This announcement was made on the first day of Dockercon EU 2017 Copenhagen where Solomon Hykes, Founder of Docker invited Kubernetes Co-Founder  Tim Hockin on the stage for the first time. Tim welcomed the Docker family to the vibrant Kubernetes world.

In case you missed out the news, here are the important takeaways from Docker-Kubernetes announcement –

  • Kubernetes support will be added to Docker Enterprise Edition for the first time.
  • Kubernetes support will be added optionally to Docker Community Edition for Mac and Windows.
  • Kubernetes and Docker Swarm both orchestrators will be available under Docker Platform.
  • Kubernetes integration will be made available under Moby projects too.

Docker Inc firmly believes that bringing Kubernetes to Docker will simplify and advance the management of Kubernetes for developers, enterprise IT and hackers to deliver the advanced capabilities of Docker to a broader set of applications.





In case you want to be first to test drive, click here to sign up and be notified when the beta is ready.

Please be aware that the beta program is expected to be ready at the end of 2017.

Can’t wait for beta program? Here’s a quick guide on how to get Multi-Node Kubernetes cluster up and running using LinuxKit.

Under this blog post, we will see how to build 5-Node Kubernetes Cluster using LinuxKit. Here’s the bonus – We will try to deploy WordPress application on top of Kubernetes Cluster. I will be building it on my macOS Sierra 10.12.6 system running the latest Docker for Mac 17.09.0 Community Edition up and running.

Pre-requisite:

  1. Ensure that the latest Docker release is up and running.

       2. Clone the LinuxKit repository:

sudo git clone https://github.com/ajeetraina/linuxkit
cd projects/kubernetes/

3. Execute the below script to build Kubernetes OS images using LinuxKit & Moby:

sudo chmod +x script4k8s.sh

All I have done is put all the manual steps under a script as shown below:





This should build up Kubernetes OS image.

Run the below command to know the IP address of the kubelet container:

ip adds show dev eth0



You can check the list of tasks running as shown below:

Once this kubelet is ready, it’s time to login into it directly from a new terminal:

sudo ./ssh_into_kubelet.sh 192.168.65.3

So you have already SSH into the kubelet container rightly named “LinuxKit Kubernetes Project”.

We are going to mark it as “Master Node”.

Initializing the Kubernetes Master Node

Now it’s time to manually initialize master node with Kubeadm command as shown below:

sudo kubeadm-init.sh

Wait for few minutes till kubeadm command completes. Once done, you can use kubeadm join argument as shown below:



Your Kubernetes master node gets initialized successfully as shown below:





It’s time to run the below list of commands command to join the list of worker nodes:

pwd
/Users/ajeetraina/linuxkit/projects/kubernetes
sudo ./boot.sh 1 --token 4cec03.1a7ccb44115f427a 192.168.65.3:6443
sudo ./boot.sh 2 --token 4cec03.1a7ccb44115f427a 192.168.65.3:6443
sudo ./boot.sh 3 --token 4cec03.1a7ccb44115f427a 192.168.65.3:6443
sudo ./boot.sh 4 --token 4cec03.1a7ccb44115f427a 192.168.65.3:6443



It brings up 5-Node Kubernetes cluster as shown below:



Deploying WordPress Application on Kubernetes Cluster:

Let us try to deploy a WordPress application on top of this Kubernetes Cluster.

Head over to the below directory:

cd linuxkit/projects/kubernetes/wordpress



Creating a Persistent Volume

kubectl create -f local-volumes.yaml

The content of local-volumes.yml look like:


This creates 2 persistent volumes:

Verifying the volumes:



Creating a Secret for MySQL Password

kubectl create secret generic mysql-pass --from-literal=password=mysql123


Verifying the secrets using the below command:
kubectl get secrets



Deploying MySQL:

kubectl create -f mysql-deployment.yaml



Verify that the Pod is running by running the following command:

kubectl get pods



Deploying WordPress:

kubectl create -f wordpress-deployment.yaml

By now, you should be able to access WordPress UI using the web browser.

Did you find this blog helpful?  Feel free to share your experience. Get in touch @ajeetsraina

If you are looking out for contribution/discussion, join me at Docker Community Slack Channel.



0
0

When Moby Meet Kubernetes for the first time

Moby has turned to be an open playground for collaborators. It has become a popular collaborative project for the container ecosystem to assemble container-based systems. There has been tremendous amount of effort put to containerize an application but what about the platform which runs those containers? Shouldn’t that be containerize too? Moby is the answer. With library of over 80+ components for all vital aspects of a container system: OS, container run time, orchestration, infrastructure management, networking, storage, security, build, image distribution, etc., Moby can help you package your own components as containers.  The Moby Project enables customers to plug and play their favorite technology components to create their own custom platform. Interestingly, all Moby components are containers, so creating new components is as easy as building a new OCI-compatible container.

While  Moby project provide you with a command-line tool called “moby” to assembles components, LinuxKit is a valuable toolkit which allows you for building secure, portable and lean operating systems for containers. It provides a container-based approach to building a customized  Linux subsystem for each type of container. It is based on containerd and has its own Linux kernel, system daemon and system services.

Mobyy

I attended Dockercon 2017, Austin TX last month and one of coolest weekend project showcased by Docker Team was running Kubernetes on Mac using Moby and LinuxKit. In case you’re completely new to Kubernetes, it is an open-source system for automating deployment, scaling and management of containerized applications. It was originally designed by Google and donated to the Cloud Native Computing Foundation. It provide a “platform for automating deployment, scaling, and operations of application containers across clusters of hosts”. It supports a range of container tools, including Docker.

moby_kubernetes





linuxkit_4_kubernetes



One of the main benefit of LinuxKit for Kubernetes includes reliable deployment, lower security footprint, easy customization around building own desired base image.Under this blog post, I am going to demonstrate how one can easily create minimal and immutable Kubernetes OS images with LinuxKit.

Pre-requisite:

  1. Install the latest Edge Release of Docker for Mac and Engine through this link.
  2. Please note that if you are using Stable Release of Docker for Mac, you won’t be able to setup Multi-node Kubernetes cluster as the stable release lack Multi-host functionality of VPNKit. Do refer this known issue. The support for multi-host networking was introduced in the latest Edge release.



Screen Shot 2017-05-11 at 9.09.37 AM

  • Ensure that Docker for Mac Edge Release gets displayed once you have installed it properly.



Screen Shot 2017-05-11 at 8.26.34 AM



Clone the LinuxKit Repository as shown:

git clone https://github.com/linuxkit/linuxkit



Build the Moby and LinuxKit tool first using the below commands:



cd linuxkit
make
cp -rf bin/moby /usr/local/bin/
cp -rf bin/linuxkit /usr/local/bin/



Change directory to kubernetes project:



cd linuxkit/projects/kubernetes



You will find the below list of files and directories:

Screen Shot 2017-05-11 at 8.31.24 AM



Let us first look at kube-master.yml file. Everything under LinuxKit is just a YAML file. This files starts with a section defining the kernel configuration, init section just lists images that is used for the init system and are unpacked directly into the root filesystem, the onboot sections indicates that  these containers are run to completion sequentially, using runc before anything else is started.  As shown below,  under the service section, there is a kubelet service defined which uses errordeveloper/mobykube:master image and build Kubernetes images.

Edit kube-master.yml and add your public SSH key to files section. You can generate the SSH key using ssh-keygen command.

Screen Shot 2017-05-12 at 9.24.03 AM



Once you have added your public SSH key, go ahead and build OS images using the below command:



sudo make build-vm-images



The above command provides you with the below output:



Screen Shot 2017-05-11 at 8.48.35 AM



Few of the important files includes:

kube-node-kernel  kube-node-initrd.img  kube-node-cmdline



Under the same directory, you will find a file called “boot-master.sh” which will help us in setting up the master node.



Screen Shot 2017-05-12 at 9.28.14 AM



Boot Kubernetes master OS image using hyperkit on macOS:



./boot-master.sh

This will display the following output:

Screen Shot 2017-05-11 at 8.50.11 AM

Just wait for few seconds and you will see LinuxKit OS coming up as shown:

Screen Shot 2017-05-11 at 8.52.58 AM



It’s easy to retrieve the IP address of the master node:



Screen Shot 2017-05-11 at 8.54.17 AM



Verify the kubelet process:

Screen Shot 2017-05-11 at 8.55.15 AM

Now it’s time to execute the script to manually initialize master with kubeadm:

/ # runc exec kubelet kubeadm-init.sh



Screen Shot 2017-05-11 at 8.56.48 AM



Copy / Save  the below command  and keep it handy. We are going to need it soon.

kubeadm join --token a5365b.45e88229a1548bf2 192.168.65.2:6443



Hence, your Kubernetes master is up and ready.

You can verify the cluster node:

Screen Shot 2017-05-11 at 8.57.48 AM

This was so easy to setup. Isn’t it? Let us create 3 node cluster directly from macOS terminal. Open up 3 new separate terminal to start 3 nodes  and run the below commands:



 ajeetraina$cd linuxkit/projects/kubernetes/
 ajeetraina$ sudo ./boot-node.sh 1 --token a5365b.45e88229a1548bf2 192.168.65.2:6443
 ajeetraina$ sudo ./boot-node.sh 2 --token a5365b.45e88229a1548bf2 192.168.65.2:6443
 ajeetraina$ sudo ./boot-node.sh 3 --token a5365b.45e88229a1548bf2 192.168.65.2:6443

Open up the master node terminal and verify if all the 3 nodes gets added:



/ # kubectl get nodes
NAME                STATUS    AGE       VERSION
moby-025000000003   Ready     18m       v1.6.1
moby-025000000004   Ready     13m       v1.6.1
moby-025000000004   Ready     15m       v1.6.1
 moby-025000000004   Ready     14m       v1.6.1



Screen Shot 2017-05-11 at 9.06.28 AM

Moby makes it so simple to setup Kubernetes cluster up and running. Under this demonstration, it created a bridge network inside VPNKit and hosts are added to that as they use the same VPNKit socket.

Thanks to Justin Cormack @ LinuxKit maintainer for the valuable insight regarding the multi-host networking functionality.

giphy



Did you find this blog helpful? Are you planning to explore Moby for Kubernetes? Feel free to share your experience. Get in touch @ajeetsraina

If you are looking out for contribution/discussion, join me at Docker Community Slack Channel.

Track The Moby Project here.
